a circuit diagram for a single-pole switch, with a green line tracing the flow of current through the components. The voltage reading at the output of the circuit increases from 0.2mV to 388.7mV as the simulation progresses, while the output voltage at the collector of the transistor rises from 0V to 4.9V. The setting is a digital simulation environment, with the circuit diagram and changing voltage readings shown on a computer screen.
