Thyristors

Description

a static electronic circuit diagram on a black background, with the text "Переключающая схема на тиристорах" at the top and "COUB by @zeleniy-transistor" in the bottom right corner. The circuit, which includes thyristors, resistors, a capacitor, and a power supply, remains unchanged throughout the loop.

Sources
4 comments
Зачем нужен конденсатор, для быстрого запуска, или как фильтр ??
Andrey LarinSep 5, 2023
@Дмитрий Фёдоров Как элемент принимающий ток и снижающий напряжение на аноде, до нуля. Иначе не закроется. Но если туда перемычку поставить то схема не будет работать.
Что за программа , для моделирования переключений ?
@По ту сторону Привет! https://www.falstad.com/circuit/circuitjs.html
